200kw/250kVA Weichai Marine Diesel Generator Set with Landking Engine

1 / 5

200kw/250kVA Weichai Marine Diesel Generator Set with Landking Engine

Customization:	Available
After-sales Service:	Global Service
Warranty:	1 Year Warranty

Send Inquiry

Product Description

Basic Info.

Model NO. CCFJ250J-W

Type Basic Diesel Generator

Installation Method Fixed

Stroke Four Stroke

Cooling Method Water Cooling

Output Type AC Three Phase

Conditions of Use Marine

Usage Common Units, Emergency Crew

Landuse Type of Unit Ordinary

Excitation Mode AC Rotating Exciter

Certificate CCS

Delivery Time 25 Days

Color Green, Black, Blue

Alternator Siemens, Marathon

Power 200kw

Weight 2200kg

Diesel Generator Wp12CD290e201

Transport Package Plywood Case

Specification 2517*1123*1628

Trademark Weichai / Huide

Origin Jiangsu

HS Code 85021200

Production Capacity 200PCS Per Month

Product Description

200KW/250KVA Weichai Marine Diesel Generator Set with Landking Engine

Weichai marine generator sets are mainly divided into primary and emergency generator sets according to their uses. The power range of primary generator sets is 16-8170kW, and the power range of emergency generator sets is 30-900kW. The primary generator sets include diesel and gas generator sets according to their fuel. The diesel generator sets include Yangchai series, Deutz series, Stey series, Landking series, Baudouin series, 170 series and CW200/250 series products. The gas generator sets mainly includes Deutz series. The manufacture and test of the generator sets comply with the general technical conditions of GB/T13032-2010 Marine Diesel Generator Set.

Notes: This model portfolio and introduction is mainly about 50Hz products, can also produce corresponding power 60Hz products.

Series	Model	Primary power/kW	Continuous power/kW	Diesel generator model	Generator Brand	Starting system	Mode of speed regulation	Emission stage	Dimensions /mm	Net weight/kg
Yangchai	CCFJ16J-W*	16	16	WP2.3CD25E200	Siemens Marathon Kang Fu	electric starter	Electronics	IMO	12667601145	438
	CCFJ20J-W*	20	20	WP2.3CD33E200		electric starter	Electronics	IMO	12667601145	473
	CCFJ24J-W*	24	24	WP2.3CD33E200		electric starter	Electronics	IMO	12667601145	488
	CCFJ30J-W*	30	24	WP2.3CD40E200		electric starter	Electronics	IMO	12667601145	523
	CCFJ40J-W*	40	40	WP4.1CD66E200		electric starter	Mechanical/electronic	IMO	15439361122	729
	CCFJ50J-W*	50	50	WP4.1CD66E200		electric starter	Mechanical/electronic	IMO	15439361122	761
	CCFJ64J-W*	64	50	WP4.1CD83E200		electric starter	Mechanical/electronic	IMO	16339361122	805
Deutz	CCFJ30J-W*	30	30	WP4CD44E120	Siemens Marathon Kang Fu	electric starter/air starter	Mechanical/electronic	IMO	17008271212	895
	CCFJ40J-W*	40	40	WP4CD66E200		electric starter/air starter	Mechanical/electronic	IMO	17008271212	945
	CCFJ50J-W*	50	50	WP4CD66E200		electric starter/air starter	Mechanical/electronic	IMO	17008271212	974
	CCFJ64J-W*	64	64	WP4CD100E200		electric starter/air starter	Mechanical/electronic	IMO	17008271212	1052
	CCFJ75J-W*	75	64	WP4CD100E200		electric starter/air starter	Mechanical/electronic	IMO	17008271212	1096
	CCFJ90J-W*	90	90	WP6CD132E200		electric starter/air starter	Mechanical/electronic	IMO	21507781385	1375
	CCFJ100J-W*	100	100	WP6CD132E200		electric starter/air starter	Mechanical/electronic	IMO	21507781385	1400
	CCFJ120J-W*	120	100	WP6CD152E200		electric starter/air starter	Mechanical/electronic	IMO	21507781385	1400
Stey	CCFJ150J-W*	150	150	WP10CD200E200	Siemens Marathon Kang Fu	electric starter/air starter	Mechanical/electronic	IMO	237510001572	2059
	CCFJ180J-W*	180	180	WP10CD238E200		electric starter/air starter	Mechanical/electronic	IMO	254210001572	2059
	CCFJ200J-W*	200	180	WP10CD264E200		electric starter/air starter	Mechanical/electronic	IMO	254210001572	2059
	CCFJ250J-W*	250	200	WP12CD317E200		electric starter/air starter	Mechanical/electronic	IMO	266910001572	2151
Landking	CCFJ250J-W*	250	200	WP12CD290E201	Siemens Marathon	electric starter/air starter	Mechanical/electronic	IMO	251711231628	2200
Landking	CCFJ300J-W*	300	250	WP13CD385E200	Siemens	electric starter/air starter	Electronical-controlled common rail	IMO	266410001532	2466
Baudouin	CCFJ350J-W*	350	350	6M33CD447E200	Siemens Kang Fu	electric starter/air starter	Electronics	IMO	301010401600	3846
	CCFJ400J-W*	400	400	6M33CD484E200		electric starter/air starter	Electronics	IMO	303010401600	3876
	CCFJ450J-W*	450	400	6M33CD550E200		electric starter/air starter	Electronics	IMO	314010401600	3896
	CCFJ500J-W*	500	500	12M33CD748E200		electric starter/air starter	Electronics	IMO	352415211927	6263
	CCFJ600J-W*	600	600	12M33CD748E200		electric starter/air starter	Electronics	IMO	359615211927	6413
	CCFJ700J-W*	700	700	12M33CD902E200		electric starter/air starter	Electronics	IMO	382015211927	6841
	CCFJ800J-W*	800	760	12M33CD968E200		electric starter/air starter	Electronics	IMO	389515211927	7060
	CCFJ900J-W*	900	760	12M33CD1100E200		electric starter/air starter	Electronics	IMO	391415211927	7267

Remark:
I. Definition of power:
Primary power of the generator set:
1. The average load rate exceeding 24 hours of running does not exceed 70%. 2. Within every 12h, with an overload by 10%, the engine can run for 1h. 3. The annual running time does not exceed 3000h.
Continuous power of the generator set:
1. The annual running time is not limited. 2. Run under constant 100% load. 3. The capacity of 10% overload.

II. The requirements of power matching:
1. For ship types with annual running time exceeding 3000h or large impact load, such as seine fishing with light, refrigerating, rake and prick, floating crane, sand suction boat and wind power installation, the model shall be selected according to the continuous power of the generator set.
2. For ship types such as inland river transport ships, coastal fishing boats and high-speed boats with domestic electricity or auxiliary pumps as the main load, the model can be selected according to the normal power of the generator set.

III. Dimension and weight information:
Dimensions and weight are for reference only. For specific product parameters and generator set model selection, please make specific docking with relevant personnel.
The delivery date of products marked with * shall be subject to the reply of the manufacturer. Product parameters and model portfolio are for reference only. Please contact relevant personnel for official information on delivery time and fishing boat model portfolio.

Product Gallery

Frequently Asked Questions

What is the power range available for these marine generator sets?

According to their application, they are divided into primary and emergency sets. The power range for primary generator sets is 16-8170kW, while emergency generator sets offer a range of 30-900kW.

What is the difference between Primary Power and Continuous Power ratings?

Primary Power allows for variable load operations with a maximum 70% average load rate within 24 hours, including a 10% overload capability for 1 hour every 12 hours. Continuous Power has no annual running time limit and operates under a constant 100% load with a 10% overload option.

Which standards do these marine diesel generator sets comply with?

The manufacture and testing of these marine generator sets strictly comply with the general technical conditions outlined in the GB/T13032-2010 Marine Diesel Generator Set standard.

Can these marine generators be built for 60Hz power requirements?

Yes. Although our primary model portfolio specifies 50Hz products, we are capable of manufacturing and supplying corresponding power configurations in 60Hz.

How do I choose the correct model based on my vessel's operational needs?

For ships with an annual running time exceeding 3000 hours or severe impact loads (e.g., floating cranes, sand suction, refrigerating ships), select models based on Continuous Power. For coastal/inland river boats with normal domestic electricity or auxiliary pump load requirements, you can select based on Primary Power.
