| Voltage (V) | Frequency (Hz) | Phase | P.F (COS) | Standby Amps (A) | Prime Amps (A) | Standby Power (KW/KVA) | Prime Power (KW/KVA) |
|---|---|---|---|---|---|---|---|
| 220 | 60 | 3 | 0.8 | 126 | 115 | 35 / 44 | 32 / 40 |
| Prime Power: | Continuous running at variable load for unlimited periods with 10% overload available for 1 hour in any 12 hour period. In accordance with ISO 8528, ISO 3046. |
| Standby Power: | Continuous running at variable load for duration of an emergency. No overload is permitted on these ratings. In accordance with ISO 3046. |
| Prime Voltage: | Can be customized according to customer’s requirement. |
Sales Promises: We provide a full line of brand new and high quality products. Each and every unit is strictly factory tested. Warranty is according to our standard conditions: a, 15 months, counted on the day sold to the first buyer; b, One year after installation; c, 1000 running hours (accumulated); subject to the earlier one. Service and parts are available from our company or distributors in your location.
| Brand / Model | WP2.3D41E201, 4-cycle |
| Air Intake System | Turbo, Water / Air cooling |
| Fuel System | PT type fuel pump, EFC Electronic governor |
| Cylinder Arrangement | "L" type, inline 4-cylinder |
| Displacement | 2.3 L |
| Bore and Stroke | 105*118 (mm) |
| Compression Ratio | 17.3 : 1 |
| Rated RPM | 1800 rpm |
| Max. Standby Power at Rated RPM | 41KW / 55HP |
| Governor Type | High-precision electronic speed control system |
| Exhaust System | |
| Exhaust Gas Flow | 168 L/s |
| Exhaust Temperature | 610 °C |
| Max Back Pressure | 10 kPa |
| Air Intake System | |
| Max Intake Pressure | 6.23 kPa |
| Consumption | 87 L/s |
| Air Flow | 752 L/s |
| Fuel System | |
| 100% (Prime Power) Load | 204.6 g/Kw.h |
| 75% (Prime Power) Load | 205.4 g/Kw.h |
| 50% (Prime Power) Load | 215.7 g/Kw.h |
| Oil System | |
| Total Oil Capacity | 16 L |
| Oil Consumption | ≤4 g/kw.h |
| Engine Oil Tank Capacity | 12 L |
| Oil Min-Pressure at Rated RPM | 345-483 kPa |
| Cooling System | |
| Total Cool Fluid Capacity | 22 L |
| Thermostat Temperature | 82-93 °C |
| Max Water Temperature | 104 °C |
Products comply with GB755, BS5000, VDE0530, NEMAMG1-22, IED34-1, CSA22.2 and AS1359 standards.
| Brand / Model | FEYDR FYD-W184J |
| Number of Phase | 3 |
| Connecting Type | 3 Phase and 4 Wires, “Y” type connecting |
| Amount of Bearing | 1 |
| Power Factor | 0.8 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Rated Hz | 60Hz |
| Exciter Type | Brushless, self-exciting |
| Voltage Control Mode | AVR (Automatic Voltage Regulator) |
| Insulation Class, Temperature Rise | H/H |
| Radio Interference | Meet the BS800 and VDE G, N |
| Telephone Influence Factor (TIF) | <50 |
| Telephone Harmonic Factor (THF) | <2% |
| Steady Voltage Adjustment Rate | ≤±1% |
| Alternator Capacity | 32KW / 40KVA |
| Alternator Efficiencies | 93.80% |
| Standard Temperature Rise | 125 -163°C Continuous |
| Cooling Method | Direct drive centrifugal blower fan |
| Air Cooling Flow | 1.035 m³/s |
The warranty is valid for 15 months from the date of sale to the first buyer, one year after installation, or 1000 accumulated running hours, whichever comes first.
Yes, the prime voltage configuration can be fully customized according to your specific local electricity requirements.
This generator set is equipped with a WP2.3D41E201 diesel engine and a FEYDR FYD-W184J model brushless, self-synchronous AC alternator.
The Smartgen HGM6110N intelligent controller provides digital readouts for voltage, current, frequency, temperature, and oil pressure. It includes automatic start/stop and safety warnings/shutdowns for high temperature, low oil pressure, over-current, overloading, and speeding.
The base-mounted fuel tank is designed to support up to 8 hours of continuous runtime at 100% full prime load.
The unit is equipped with a GMJY-32 silenced canopy model, which limits noise indicators to LP7m-75dB.
