* The above fuel consumption is calculated with the natural gas whose heat value is 35.8MJ/Nm³
Dimensions and Weights
Content
Open Type
Soundproof Sets
Dimensions: L (mm)
2450
3200
Dimensions: W (mm)
1100
1200
Dimensions: H (mm)
1550
1650
Weights (kg)
1150
1835
Engine Brand & Model: HGT6B
Engine Parameter
Specification
Engine Parameter
Specification
No. of Cylinders
6 in-line
Engine Power (kW)
100
Cycle
4 Stroke
Cylinder Type
Dry
Bore * Stroke (mm)
102 x 120
Compression Ratio
10.5:1
Induction
Turbocharged & Aftercooled
Displacement (L)
5.88
Cooling Method
Water cooled
Governing Type
Electronic
Starting Method
24V DC motor
Coolant Capacity, with Radiator (L)
29.26
Lubricant Oil
15W40-CF4 or above grade
Oil Pan Capacity (L)
16
Preparation Before Genset Starting
Before starting the genset, check and adjust the entire generator set to keep it in optimal condition. The connection and fixing of every module must be reliable. Ensure that the cooling system and electrical starting system show no leakage or looseness, and verify that the transfer switch is flexible and lubrication is adequate. The gas supply system must function normally; otherwise, immediate repair or adjustment is required before restarting.
All supplied gas gensets have completed testing and can be used directly under load. For initial usage, it is advised to operate at 80%-90% of full load. For continuous usage, please maintain the load at 75%-80% of full load.
Pre-Start Checklist
Clean dust, water traces, oil stains, and rust on the genset.
Check if all connecting parts and fastening components are secure, and verify that moving parts rotate flexibly without jamming.
Confirm all connecting wires are properly attached, firm, and show no signs of loosening or dropping off.
Verify that the gas intake pipe is unobstructed and turn on the gas intake pipe switch.
Confirm there is sufficient oil in the oil pan and the cooler is fully filled with coolant.
Set all control switches to their corresponding operational positions, ensuring the air breaker is positioned at "OFF".
Frequently Asked Questions
What is the rated power and voltage of this gas generator?
The generator set has a rated power of 100 kVA (80 kW) at a 0.8 power factor. Its standard voltage configuration is 50Hz, 380/220V, utilizing 3 phases and 4 wires.
What are the engine specifications for this generator set?
It features a water-cooled, 4-stroke, 6 in-line cylinder HGT6B engine with turbocharged and aftercooled induction. It has a displacement of 5.88L and a compression ratio of 10.5:1.
What is the expected fuel consumption at full load?
The fuel consumption is 25.14 Nm³/hr at 100% load. This is calculated using natural gas with a heat value of 35.8MJ/Nm³.
What are the dimensions and weights of the different configurations?
The open type configuration measures 2450x1100x1550 mm and weighs 1150 kg. The soundproof set configuration measures 3200x1200x1650 mm and weighs 1835 kg.
What load ratio is recommended for initial and continuous operation?
It is recommended to run the generator at 80%-90% of its full load for initial use. For continuous operation, maintaining a load ratio of 75%-80% of full load is advised.
What lubricating oil grade and quantity should be used?
The engine requires 15W40-CF4 or above grade lubricant oil, and the oil pan has a total capacity of 16 liters.
